Autocad Productivity Tools
MicroCAD Productivity Toolkit for AutoCAD
MicroCAD Productivity Toolkit for AutoCAD is a batch of practical and valuable tools that will reduce the number of tiresome tasks and make your work in AutoCAD faster and efficient.
AutoCAD Toolkit includes nine sets of tools:
Top Features
Selection Tools
Selection Filter
The Selection filter tool helps selecting AutoCAD entities from a tree like control.
Select Elements on Layer
Select all entities on layer just by selecting one element on that particular layer.
Show Xdata
Review object extended entity data on a specific item if it exists.
Modify Tools
Spreadsheet Properties
Use this powerful tool to populate Excel like spreadsheet with AutoCAD entity properties. Take advantage of excel functionality to manipulate properties and push changes back to the drawing.
Align
Align objects to selected line. You can optionally rotate selected objects to match the rotation of line and define object insertion point.
Geometry Tools
3D Fillet
Fillet a 3D polyline by inserting tessellated arc.
3D Offset
Command similar to AutoCAD offset with option to define vertical offset. Works also on 3D Polylines.
Convert to 3D Polyline
Convert 2D polylines into 3D polylines.
Annotate Tools
Label Elevation
Define a base point location and elevation then label additional elevations by selecting points on screen. These elevations are in relation to the basepoint location and elevation.
Label Slope
Label slopes of a 2D or 3D polyline. 2D polyline’s slopes are calculated in XY plane. 3D polyline’s slopes are calculated from Z vertex coordinate.
Polyline Wipeout
Create wipeout element around polyline to improve polyline’s visibility. You can define buffer of your wipeout.
Block Legend
Create a legend of blocks in your drawing in one instance. Define the blocks that should appear in legend and optionally enter a description for each block.
Hatch Legend
Create a legend of hatches in your drawing in one instance. Define the hatches that should appear in legend and optionally enter a description for each hatch pattern.
Linetype Legend
Create legend of line types in your drawing in one instance. Define the line types that should appear in legend and optionally enter a description for each line type.
Text Tools
Sum of Text
Summarize selected text objects by selecting them on screen then insert the result in the drawing as a piece of text.
Total Length
Calculate the total length of all selected linear objects.
Layout Tools
Create Viewport
Position your viewport by defining paper size, margins and scale. Appropriate rectangle will be presented in model space enabling you to interactively position it by defining location and rotation.
Rename Sheets
Renaming multiple sheets can be a tedious task if you do it one by one. With this tool you can rename multiple sheets at once. Tool also changes layout names.
MicroCAD Autodesk Tools is a set of essential productivity plug-ins that will make your work in AutoCAD fast, easy and efficient.
- Streamline your everyday tasks
- Reduce the amount of tedious work
- Become more productive
- Do things that are not possible with out-of-the-box AutoCAD
